Model
|
OB-PT-AL-50W
|
OB-PT-AL-60W
|
OB-PT-AL-75W
|
OB-PT-AL-100W
|
OB-PT-AL-150W
|
OB-PT-AL-170W
|
|
Power
|
50W
|
60W
|
75W
|
100W
|
150W
|
170W
|
|
Lumens
(120lm/w & 130lm/w)
|
6,000lm
|
7,800lm
|
9,000lm
|
13,000lm
|
19,500lm
|
20,400lm
|
|
Size
|
450*450*650mm
17.7*17.7*25.6in
|
450*450*650mm
17.7*17.7*25.6in
|
450*450*650mm
17.7*17.7*25.6in
|
450*450*650mm
17.7*17.7*25.6in
|
450*450*650mm
17.7*17.7*25.6in
|
450*450*650mm
17.7*17.7*25.6in
|
|
Color Temp
|
3000K / 4000K / 5000K / 5700K
|
|||||
|
Housing
|
Die casting aluminum housing with reliable powder coating for harsh outdoor environments
|
|||||
|
Operation Temp
|
-40°C to 50°C
|
|||||
|
LED Emitter Life
|
50,000 hours
|
|||||
|
Input Voltage
|
100-277Vac
|
|||||
|
Power Factor
|
PF>0.95
|
|||||
|
LED Source
|
Osram LED
|
|||||
|
Beam Angle
|
120°
|
|||||
|
CRI
|
>73
|
|||||
|
Power Supply
|
Meanwell Driver
|
|||||
|
Warranty
|
5 years factory warranty
|
|||||
| Model | LED (Pcs) | Wattage (W) | Colour | Lumens (Lm) | Size (mm) |
Beam Angle(°) |
Input Voltage(V) |
Waterproof (IP) | Download |
| OB-PT-AL-50W | 50W | WW,NW,CW | 130Lm/w | 450*450*650mm | 120° | 100-277Vac | IP65 |  |
|
| OB-PT-AL-60W | 60W | WW,NW,CW | 130Lm/w | 450*450*650mm | 120° | 100-277Vac | IP65 | |
|
| OB-PT-AL-75W | 75W | WW,NW,CW | 130Lm/w | 450*450*650mm | 120° | 100-277Vac | IP65 | |
|
| OB-PT-AL-100W | 100W | WW,NW,CW | 130Lm/w | 450*450*650mm | 120° | 100-277Vac | IP65 | |
|
| OB-PT-AL-150W | 150W | WW,NW,CW | 130Lm/w | 450*450*650mm | 120° | 100-277Vac | IP65 | |
|
| OB-PT-AL-170W | 170W | WW,NW,CW | 130Lm/w | 450*450*650mm | 120° | 100-277Vac | IP65 | |
LED Street Light
