Use AL 1070 Cooling fin heat sink, excellent heat dissipation
16 Inch aluminum reflector/PC reflector, >93% transparency protection PC cover.
Constant current design, big heat dissipation space to ensure LED lighting efficiency and life span
We can provide 60°120°for 16 Inch aluminum reflector and 60°PC reflector.
|
category： |
parameter |
|
Base |
N/A |
|
Power |
80±2W |
|
Input Voltage |
85V-265Vac/50Hz |
|
light type |
2835 |
|
Dimension |
Φ402*358mm |
|
service life |
50000h |
|
Water Class |
IP20 |
|
weight |
≈2.7KG |
|
Beam Angle |
90° |
|
POWER FACTOR |
0.9 |
|
SURFACE TEMPERATURE： |
<70℃ |
|
SAFETY ASSURANCE:CE RoHs |
|
|
Inner box |
224*224*285mm |
|
QTY/Carton |
8PCS/Carton |
|
20pcs Aluminum cover size: |
S:570*570*390mm |
|
Gross Weight： |
19KG |
|
Export carton |
468*468*600mm |
|
20pcs Aluminum cover gross weight |
12.5KG |
|
CCT |
2700-3700K WW 3700-5000K NW 5000-7000K CW |
|
CRI: |
≥70 |
|
Luminous |
6400±5%lm 6500±5%lm 6550±5%lm |
| Model | LED (Pcs) | Wattage (W) | Colour | Lumens (Lm) | Size (mm) |
Beam Angle(°) |
Input Voltage(V) |
Waterproof (IP) | Download |
| OB_HB-80W | 2835 | 80±2W | 2700-3700K WW;3700-5000K NW;5000-7000K CW | 6400±5%lm;6500±5%lm;6550±5%lm | Φ402*358mm | 90° | 85V-265Vac/50Hz | IP20 |  |
Suitable for Warehouses, Production and logistics workshops, Retail stores, Theme restaurants, Amusement parks, Indoor stadiums and public places, and other industrial and commercial lighting purposes.
